Advanced technology 63-800mm double wall corrugated drain pipe production line manufactured in China

FOB Reference Price:Get Latest Price
$29,999.00 - $999,999.00 / Sets | 1 Set/Sets double wall corrugated drain pipe production line (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Production Capacity:
1-7m/min
Power(W):
20-220KW
Application:
Other
Place of Origin:
Jiangsu, China
Brand Name:
Techno
Model Number:
TEGC
Dimension(L*W*H):
L10000*W1800*H2000mm
Main Electric Components:
Siemens
Inverter:
ABB
Self Protective System:
Over current & over pressure alarm protection
Processing Type:
Extrusion Machine
Weight:
8000kg
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
12 Months
Type:
Pipe Production Line
Voltage:
220/380/415/420/440V
Condition:
New
Certification:
CE ISO
Pipe Material:
Other
Supply Ability
Supply Ability:
5 Set/Sets per Month double wall corrugated drain pipe production line
Packaging & Delivery
Packaging Details
Standard Export Seaworthy Packing double wall corrugated drain pipe production line
Port
Shanghai
Lead Time :
50 Working Days
Company Information

About us

Zhangjiagang Techno Machinery Co., Ltd.

Techno Machinery is a certified manufacturer,exporter and supplier of plastic processing machinery.Made of quality raw material and using world top class technology, our machines are widely appreciated for their attributes like efficient and consistent performance, lower power consumption, durable and corrosion resistance. Our products incorporate user-friendly operations and controls, including parts that resist wear and tear and conform to prescribed specifications of plastic manufacturing units.

Product Description

Advanced technology 63-800mm double wall corrugated drain pipe production line manufactured in China

Product details

Main Electric ComponentsSiemens
InverterABB
Self Protective SystemOver current & over pressure alarm protection
Processing TypeExtrusion Machine
Product Keywords63-800mm double wall corrugated drain pipe production line


Machine Illustration:

Double wall corrugated pipe is a new type pipe possessed cyclic annular outer wall and smooth inner wall.Currently it has been very mature in the processing and using technology.The production line is of digital centralized control,dual extrusion and double diversion.

It consists of single screw extruder,co-extrusion die-head,forming machine,mould block,cooling tank,cutter and stacker.One extruder for the pipe external wall,one extruder for the pipe internal wall.Thereby,you have the possibility to use different materials for each pipe layer,to use different colorsand to produce flexible pipes.

Double wall corrugated pipe has the characteristic of reasonable structure,heat resistance -40°C-60°C,anti-corrosion,high strength,strong seismic performance and energy saving,etc.It mainly used in water distribution,supply,drainage,irrigation,air exhaust,mine ventilation and so on.



Main Technical Parameter

Pipe Diameter
Single Screw Extruder
Forming Machine
Spray Bath
Planetary Saw
Stacker
50-160 (OD mm)
SJ-65 x 30
SJ-90 x 30
SBZ160A

SQG160A
JGJ1120
110-250 (OD mm)
SJ-90 x 30
SJ-65 x 33
SBZ250
LQM2550
QG250A
JGJC250
200-400 (ID mm)
SJ-90 x 30
SJ-75 x 33
SBZ500C
LQM6330
QG6330A
JGJA500
500-800 (ID mm)
SJ-90 x 33
SJ-120 x 33
SBZ1000C
LQM1000
QG9030A
JGJ1000
800-1200 (ID mm)
SJ-120 x 33
SJ-150 x 33
SBZ1500C
LQM1500
QG1500
JGJ1500
Our Advantages

 High Quality---- Quality Raw Material, Advanced Facilities, Fine Procedures.

 High Productivity

 Fast Delivery

 Leading Level R & D Department

 Experienced Marketing Manager

 Professional Design Department

 Accept OEM & ODM

 Excellent After-sales Service

Packaging & Shipping

PACKAGE:

If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.

DELIVERY TIME:

50 days after confirming order,detail delivery date should be decided according to
production season and order quantity.

FAQ

Q1.What’s your advantage? Why we choose you?

A:1)10 Years experience of plastic extrusion production and R&D.We have the most professional techniques and team. More advantage in price

2)Great production capacity Sustainable Supply . According to customer requirements, We support the customized include package.

3)We use 100% new materials and the best production process, in consequence our defective rate is lower than 0.01%.

Q2.What’s the Payment?

A:T/T would be better with quick transfer and few bank fees. LC could also be accept, but the procedure is complex and the fee is high.

Q3.Are you a factory or trading company?

A:We are a professional manufacturer. We are warmly welcome clients from worldwide to visit our factory and cooperate with us.

Q4.What's the After-sales Service?

A:1)Training how to instal the machine, training how to use the machine.
2)Engineers available to service machinery overseas.
